Faster Project Completion
Dry installation helps reduce site delays and speeds up handover timelines.
PWS FLOOR 6000 Series Calcium Sulphate Access Floor Panels are engineered for high-load, high-performance environments requiring superior structural strength, acoustic stability, fire safety, and long-term operational reliability.
Designed using high-density calcium sulphate core technology, the 6000 Series delivers advanced flooring performance for data centres, control rooms, smart infrastructure, and critical operational facilities.
Electrical Systems
Data Cabling
Communication Networks
HVAC Services
Cooling Infrastructure
| Parameter | Specification |
|---|---|
| Panel Size | 600 mm x 600 mm |
| Panel Thickness | 34 mm |
| Core Material | Fiber reinforcement, compressed calcium sulphate |
| Core Density | 1500 kg/m³ |
| Encapsulation | Galvanized steel 0.5 mm bottom |
| Edge Protection | PVC edge band 0.45 mm thick |
| Fire Resistance | EN 13501-1: Class A1 |
| Fire Rating | ASTM E84 Class 1 or A |
| RoHS | Metal - RoHS 4 / Non Metal - RoHS 10 |
| Water Absorption | 24 Hours - 2.40% |
| Recyclability | 97% recyclable content |
| Concentrated Load | ≥ 6.5 kN Class 4/5 |
| Ultimate Load | ≥ 20 kN |
| Uniform Distributed Load | ≥ 26 kN/m² |
| Impact Resistance | Class 2 / Class 3 |
| Rolling Load | ≥ 10,000 cycles @ 3.0 kN |
| Pedestal Axial Load | ≥ 22 kN |
| Pedestal Range | 300 mm - 2000 mm |
Choose from a range of factory-laminated surfaces:
Organized underfloor routing for electrical and communication systems.
Our panels are versatile and designed to support a wide range of industries, including:
Concentrated Load Performance
Rolling Load Resistance
Impact Resistance
Dimensional Accuracy
Pedestal Strength
Structural Stability
Indoor Air Quality Certified
Low VOC, safer indoor air
Hazardous substance restricted compliant
Verified sustainable product standard
Supports green building standards
Low flame and smoke spread
Assured installation and stability
Quality and environmental management
High load performance certified
A modular raised flooring system engineered for faster execution, cleaner installation, and future-ready commercial infrastructure.
Dry installation helps reduce site delays and speeds up handover timelines.
Minimizes dependency on heavy wet-work and traditional civil sequencing.
Allows MEP, data, interiors, and workspace services to progress efficiently.
Organized, low-mess execution suitable for premium commercial environments.
Easy access for maintenance, upgrades, cabling changes, and space planning.
Reusable modular flooring approach designed for efficient future adaptation.
Engineered flooring systems for high-load, high-uptime digital infrastructure.
Professional floor solutions designed for modern, efficient workspaces.
Built to support high-traffic terminals with long-term performance.
Reliable flooring infrastructure for connected urban environments.
Durable systems suited for demanding operational and production zones.
Stable, functional flooring for continuous monitoring and command spaces.
Find answers to common questions about our raised access flooring systems, applications, technical specifications, certifications, and installation capabilities.
Calcium Sulphate Access 6000 Floor Panels are high-performance raised access flooring panels engineered for mission-critical environments. They feature a high-density calcium sulphate core with galvanized steel reinforcement, providing exceptional load-bearing capacity, fire resistance, acoustic performance, and long-term durability.
The 6000 Series is widely used in data centres, control rooms, command centres, telecommunication facilities, server rooms, industrial monitoring rooms, smart city infrastructure projects, and other critical operational environments.
The PWS FLOOR 6000 Series panels offer a concentrated load capacity of 6.5 kN, an ultimate load of 13.5 kN, and a uniformly distributed load of 26 kN, making them suitable for heavy-duty applications.
The standard panel size is 600 x 600 mm and is available in thickness options of 30 mm and 34 mm, ensuring compatibility with various infrastructure requirements.
The panels are available with HPL, carpet, vinyl, linoleum, and bare finishes to meet different design and operational requirements.
Raised access flooring creates an underfloor service zone where electrical wiring, data cables, communication networks, and HVAC systems can be organized efficiently while remaining easily accessible for maintenance and upgrades.
Calcium sulphate offers superior structural strength, excellent fire resistance, acoustic insulation, dimensional stability, and moisture resistance, making it one of the most reliable materials for raised flooring systems.
Yes. The 6000 Series features a Class A1 non-combustible calcium sulphate core and complies with international fire safety standards including EN13501, REI-60, and ASTM E84 Class A.
